Design Features of Hayward Tyler Submersible Motors
Our electro-submersible motors can be arranged in standard or inverted configurations to suit the most demanding applications. We use a wet-wound, water/glycol filled motor that is environmentally friendly and has “run with leak” capability.
• Wet-wound, water/glycol filled motor.
• Injection molded cable joints
• Enclosed to IP68
• Variety of materials available, up to Super Duplex
• 8+ year service intervals
• Product lubricated bearings (radial and thrust)
• Integral thrust bearing/aux. impeller for improved cooling
• Run with leak capability
• Header tank available for visual condition check
• Condition monitoring using Motor Current Signature Analysis available as an option
Codes & Specifications
Operating Data
US | SI | |
---|---|---|
Power | Up to 3,350 hp | Up to 2.5 MW |
Voltage | Up to 13.8 kV | Up to 13.8 kV |
Poles | 2, 4, 6, 8 | 2, 4, 6, 8 |
VFD Compatible | Yes | Yes |
Codes and Compliances:
- API 610
- API 541
- IEC 60034
- NEMA MG-1
Pressure Design:
- ASME
- EN
- PED
Quality:
- NORSOK
- DNV
- ISO
- Subsea Electrical Power Standardization (SEPS)
Applications
Hayward Tyler Submersible Motors are ideal for applications such as:
- Seawater Lift
- Firewater Lift
- Caisson Drain Pump
- Hull Ballast and De-Ballast Pumps
- Water Injection
- Cooling Water Pumps
- Booster Pumps
- Jockey Pumps
- Process Pumps
- Marine Thrusters
- Marine Secondary Propulsion
- Mud Rise Pumps
- Petrochemical Fluids
- Cavern Pumps
Typically Used On:
- FPSO
- FLNG
- Offshore Windfarms
- Fixed Platforms
- Tension Leg Platforms
Documents
Download our brochure to read more about all Hayward Tyler Submersible Motors:
Sectional Arrangement
Inverted Submersible Motor
Hover over the numbers below for details about each feature
![](https://haywardtyler.com/wp-content/uploads/2020/07/Inverted-Submersible-2.jpg)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-01.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-01-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-02.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-02-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-03.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-03-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-04.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-04-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-05.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-05-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-06.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-06-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-07.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-07-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-08.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-08-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-09.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-09-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-10.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-10-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-11.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-11-hover.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-12.png)
![](https://haywardtyler.com/wp-content/uploads/2019/07/dot-12-hover.png)
Sectional Arrangement
Standard Submersible Motor
Hover over the numbers below for details about each feature
![](https://haywardtyler.com/wp-content/uploads/2020/07/submersible-motor-standard.jpg)
