Subsea Motors for Oil & Gas Industry

Design Features

Codes & Specifications

Applications

Documents

Design Features

Design Features of Hayward Tyler Subsea Motors

Our deepwater subsea motors are built to the highest standards to provide exceptional performance and reliability at depths up to 3000m. Our engineered designs offer proven 8-year service intervals and have the following key features:

Qualified subsea penetrator for ROV connection
Wet-wound, water/glycol filled motor
Enclosed to IP68
Independently qualified cable jointing method
Internal pressure compensator provides positive motor pressure
8+ year service intervals
Latest T3 product lubricated bearings (radial and thrust)
Integral thrust bearing/aux. impeller for improved cooling
Condition monitoring packages available

Codes & Specifications

Operating Data

	US	SI
Power	Up to 8,000 hp	Up to 6 MW
Voltage	Up to 13.8kV	Up to 13.8kV
Speed	Up to 6,000 rpm	Up to 6,000 rpm
VSD Compatible	Yes	Yes
Depth	Up to 10,000 ft	Up to 3000m

Codes and Compliances

API 541
IEC 60034
NEMA MG-1

Pressure Design:

ASME
EN
PED

Quality:

NORSOK
DNV
ISO
Subsea Electrical Power Standardization (SEPS)

Applications

Hayward Tyler Subsea Motors are ideal for the following applications:

Seawater Injection
Multi-Phase Boosting
Crude Oil Boosting
Produced Water Re-Injection
Deepwater Power Solutions

Documents

Download our brochure to read more about all Hayward Tyler Subsea Motors:

HT Submersible Subsea Brochure

Sectional Arrangement

Hover over the numbers below to see details about each feature

Photo Gallery

Click to view larger image

Design Features of Hayward Tyler Subsea Motors
